Watec WAT-250D2 1/3" 0.02Lux CCD Camera


Condition:New
Model:Watec WAT-250D2
Image sensor:1/3¡ålnterline transfer CCD
minimum illumination : 0.02Lux F1.2



While maintaining the same small size as the Watec WAT-250D, the Watec WAT-250D2 1/3" Color Camera captures images in minimal light conditions of 0.05 lux in over 540 TVL of high resolution true color producing imagery. This color camera utilizes the DSP technology providing crisp, vivid colors empowering your team with the advantage to clearly identify colors as they appear to the human eye. Further meeting your requirements of perfection is this cameras¡¯ built in feature of pixel correction, enabling you the ability to erase up to 32 hot pixels for those application requiring absolute blemish free video.

Watec WAT-250D2 Features:

*  540TVL;
*  Minimum illumination : 0.02Lx/ F1.2;
*  White spots elimination function;
*  The new back focus mechanism.
*  Compact & lightweight
*  High sensitivity
*  High resolution (540 TVL)
*  Blemish correction
*  Flickerless EI
*  Color rolling less ATW
*  Screw mount
*  White balance control
*  Electronic iris
*  Supports Automatic Gain Control (AGC)
*  Backlight compensation
*  Gamma correction
*  Video/DC iris auto-select
*  Iris level control

Watec WAT-250D2 Specifications:

Model WAT-250D2(NTSC) WAT-250D2(PAL)
Image Sensor 1/3" CCD
total pixels 811(H)*508(V) 795(H)*596(V)
Effective Pixels 768(H)*494(V) 752(H)*582(V)
Pixel Size 6.35um(H)*7.4um(V) 6.5um(H)*6.25um(V)
imaging system Ye, Cy, Mg, and G complementary color mosaic filters on chip
Synchronization mode internal synchronization
Scanning system 2:1 interlaced scanning
video output synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance
resolution ratio(H) More than 540 TVL(Center)
minimum illumination 0.02lx. F1.2
S/N More than 50dB(MGC=0dB,¦Ã= 1.0)
AE Mode Fixed 1/60 - 1/100 sec. 1/50 - 1/120 sec.
EI 1/60 - 1/100000 sec.(flicker suppress) 1/50 - 1/100000 sec.(flicker suppress)
WB ATW(color rolling less), PWB,
automatic gain control 0-38dB(ON) / 0dB(OFF)
Gamma Features : ¦Ã¨P0.45(ON)/¦Ã= 1.0(OFF)
lens Video /DC(EIAJ arrangement,Auto-select)
Image level 100IRE(ON)/75IRE(OFF)
BLC ON/OFF
Power voltage DC + 12V + -10%
White defect correction Up to 32 pixels
power consumption 1.74W(145mA)
Operating Temperature -10 - +50¡æ(Frost-free knot)
Storage Temperature -30 - +70¡æ(Frost-free knot)
Work /Storage humidity Lower than 95£¥RH
Mount CS (Adjustable back focus)
Weight About 90G

Watec WAT-250D2 High Sensitivity 1/3 540TVL Color CCD Camera
