WATEC WAT-2500 1/2.8-inch Rolling Shutter Compact Low Light Color Analog Camera
The Watec WAT-2500 is a high-sensitivity analog color camera engineered for demanding low-light and precision imaging applications in a compact housing. Featuring a 1/2.8-inch back-illuminated CMOS sensor, the WAT-2500 delivers crisp, accurate color reproduction with minimum illumination down to 0.0004 lx (F1.2, AGC HIGH, shutter ℅15), making it ideal for environments where light is limited or tightly controlled.
This camera offers advanced image tuning via On Screen Display (OSD) using an optional remote controller, allowing precise adjustment of AGC, gamma, white balance, wide dynamic range, noise reduction, and defog functions. Built with a CS-mount and adjustable back focus, the Watec WAT-2500 integrates easily into machine vision, inspection, and monitoring systems where size, performance, and reliability are critical.
Features:
* 1/2.8" BSI CMOS image sensor for high sensitivity
* Minimum illumination: 0.0004 lx (F1.2, AGC High)
* High signal-to-noise ratio (45 dB or more)
* On-Screen Display with remote controller (optional)
* Adjustable WDR, gamma, AGC, noise reduction, defog
* DC auto iris and CS-mount compatibility
* Compact, lightweight body (approx. 78 g)
* Made in Japan quality and reliability
Applications:
* Machine Vision
* Lab Inspection
* Industrial Process
* Scientific Imaging
* Surveillance Systems
* Component Testing
Specifications:
Model
Watec WAT-2500
Video Standard
NTSC / PAL
Pick-up Element
1/2.8-inch BSI CMOS image sensor
Effective Pixels
1945 (H) ℅ 1097 (V) *
Unit Cell Size
2.9 µm (H) ℅ 2.9 µm (V)
Color Filter
RGB primary color Bayer mosaic
Imaging System
Progressive scan
Sync System
Internal
Scanning System
Progressive
Video Output
Composite 1.0 V(p-p), 75 次, unbalanced (BNC)
Setup Level
7.5 IRE (NTSC), 0 IRE (PAL)
Horizontal Resolution
More than 570 TVL (Center)
Minimum Illumination
0.0065 lx F1.2 (AGC HIGH = 72 dB, shutter OFF)
0.0004 lx F1.2 (AGC HIGH = 72 dB, shutter ℅15)
S/N Ratio
More than 45 dB (AGC OFF = 0 dB, 污 = 1.0)
Exposure Modes
AE mode, Fixed, EI
Shutter (NTSC)
Manual: 1/30, 1/60, 1/120, 1/180, 1/240, 1/300 sec.
EI: 1/30 每 1/10000 sec.
Shutter (PAL)
Manual: 1/25, 1/50, 1/100, 1/150, 1/200, 1/250 sec.
EI: 1/25 每 1/10000 sec.
AGC
0每36 dB (LOW), 0每50 dB (MID), 0每72 dB (HIGH), OFF (0 dB)
Composite video (BNC), Power in, Remote controller (RC-01), Auto iris
Power Supply
DC +12 V ㊣10%
Power Consumption
2.52 W (210 mA)
Operating Temperature
−10 ∼C to +50 ∼C
Storage Temperature
−30 ∼C to +70 ∼C
Operating / Storage Humidity
95% RH or less (no condensation)
Lens Mount
CS mount (back focus adjustable)
Weight
Approx. 78G
Accessories
WPDC12 (DC plug), Hex wrench
