The Watec W-02CDB3 1/3" Camera with 2.8 to 10mm Lens\ is a high-resolution, exposure, board camera with a built-in varifocal auto-iris lens. W-02CDB3 is a complete package for the color board solution and comes with 450 TVL resolution.
WATEC W-02CDB3 Features:
* 450 TVL
* 2:1 Interlace Scanning System
* Internal Synchronizing System
* 380k Effective Pixels
* F2.8-10mm zoom auto iris lens (built-in);
* High resolution;
* Automatic white balance;
* DC12V;
* AGC;
* Electronic shutter;
* DC12V;
* Image level switch.
WATEC W-02CDB3 Specifications:
| Model |
WAT-02CDB3(NTSC) |
WAT-02CDB3(PAL) |
| Image Sensor |
1/3" CCD |
| total pixels |
811(H)*508(V) |
795(H)*595(V) |
| Effective Pixels |
768(H)*494(V) |
752(H)*582(V) |
| Pixel Size |
6.4um(H)*7.5um(V) |
6.5um(H)*6.3um(V) |
| Synchronization mode |
internal synchronization |
| Scanning system |
2:1 interlaced scanning |
| video output |
synthesize,Y/C£º1.0 V(P-P),75¦¸,imbalance |
| resolution ratio(H) |
More than 450 TVL(Center) |
| minimum illumination |
3.0lx. F1.6 |
| S/N |
More than 50dB(AGC=3dB,¦Ã= 1.0) |
| AE Mode |
Fixed |
1/60-1/100 sec. |
1/50-1/120 sec. |
| 1/250,1/500,1/1000,1/2000,1/5000,1/10000,1/20000,1/50000 sec. |
| Built-iris lens |
DC DRIVE |
| WB |
ATW, Preset(3200K, 5100K,8200K) |
| automatic gain control |
3-24dB |
| Gamma Features : |
¦Ã¨P0.45 |
| Image Level |
100IRE / 75IRE |
| Mirror image |
On/Off |
| Power voltage |
DC + 12V¡À10% |
| power consumption |
1.26W(105mA) |
| Operating Temperature |
-10 - +40¡æ(Frost-free knot) |
| Storage Temperature |
-30 - +70¡æ(Frost-free knot) |
| Work /Storage humidity |
Lower than 95£¥RH |
| lens |
Built-in zoom lens, F = 2.8 to 10 mm F1.6 (2.8) |
| Weight |
About 35G |
|
