Watec Full-Color HD Video WAT-1100MBD G3.6 NTSC Color Day/Night Board Camera Ultra-Compact Design
Description:
Audio Video Supply is the Watec WAT-1100MBD G3.6 NTSC, a powerful miniature day/night camera built for ultra-low-light performance and seamless integration.
The Watec WAT-1100MBD G3.6 NTSC is a compact, high-performance day/night board camera designed for precision imaging in both daylight and near-total darkness. Featuring a 1/3.2 BSI CMOS sensor, it delivers 750 TVL resolution for sharp, true-to-life imaging while maintaining a discreet, low-profile design perfect for covert installations and specialized integrations.
With an ultra-low-light sensitivity of 0.005 lx F1.8 (AGC 54dB), this camera excels in challenging lighting conditions, making it ideal for security, surveillance, and industrial applications. The 3.6mm M12 lens provides precise focus and enhanced clarity, ensuring high-quality imaging across various environments. Bundled with the CB-01 power/video harness and AD901 1212 P5 power supply, the WAT-1100MBD G3.6 NTSC is ready for easy integration right out of the box.
Searching for a high-performance miniature day/night camera? Audio Video Supply proudly carries the WAT-1100MBD G3.6 NTSC, delivering superior low-light imaging for professional applications.
Features:
* Day/Night Functionality 每 High-quality imaging in both bright and ultra-low-light conditions.
* Ultra-Compact Design 每 Miniature size allows for discreet installation and seamless system integration.
* Full-Color HD Video 每 Captures vivid, true-to-life images in multiple resolutions, including 1920℅1080 and 1280℅720.
* High Sensitivity 每 Operates in 0.005 lx F1.8, ensuring clear visuals in near-total darkness.
* Superior Resolution 每 Produces crisp, high-quality imaging with 750 TVL resolution.
* Complete Setup 每 Includes CB-01 harness and AD901 1212 P5 power supply for immediate use.
Specifications:
Pick-up element
1/3.2 inch BSI CMOS image sensor
Number of effective pixels
1280(H) ℅ 960(V)
Unit cell size
3.5米m(H)℅3.5米m(V)
Imaging system
RGB+W array mosaic filters on chip
Synchronizing system
Internal
Scanning system
Progressive
Video output
Composite: 1.0 V(p-p) 75次 (Unbalanced)
Resolution (H)
More than 750TVL (Center)
Minimum illumination
0.005 lx F1.8 (AGC=54dB)
S/N
More than 55dB (AGC=OFF﹜ 污=1.0)
Function settings
OSD (On Screen Display) operated by remote controller
Mutiple exposure WDR: ON (Level selectable) / OFF
ATR : ON (Level selectable) / OFF
Lens Iris
DC
Back Light Compensation
OFF / BLC / HLC
Defog
OFF / AUTO (Correction level selectable)
Privacy Mask
16masks
Mirror Image
OFF / V-FLIP / H-FRIP / HV-FLIP
Sharpness
0 - 255 (SHARPNESS)
Power Supply
DC+5V - 12V
Power Consumption
0.72W (60mA) ↗12V
Operating Temperature
-10 - +50⊥
Storage Temperature
-30 - +70⊥
Operating / Storage humidity
95% RH or less (Without condensation)
Lens Mount
M12 P=0.5
Standard Lens
M3718BC-12ㄗf3.7 F1.8ㄘ
Weight
Approx. 13.5g
Accessories
4P Cable, I/O Cable
