lightspot:
* 1/4" COLOR
* 480 TV LINES
* OSD CONTROL PANEL
* 22X MOTOR ZOOM. AUTO FOCUS. AUTO IRIS
* FREEZE FUNCTION. CROSS LINE
* ZERO COLOR ROLLING
| ITEM: |
DESCRIPTION: |
| Model No. |
MTV-64G2DHN |
MTV-64G2DHP |
| TV System |
NTSC |
PAL |
| Picture Element: |
811(H) X 508(V) |
795(H) X 596(V) |
| Scanning System |
525 lines, 60 fields/sec |
625 lines, 50 fields/sec |
| Sync system: |
Internal / VD-Lock |
| Minimum Illumination: |
Typical |
1.5 Lux of F1.2 |
| Star Light Mode |
0.03Lux of F1.2 |
| Resolution: |
480 TVL |
| S/N Ratio: |
52dB ( MIN ) / 60dB ( TYP ) (AGC OFF) |
| Auto iris: |
A.E.S. / Manu: 8 Step |
| Lens: |
22X optical ZOOM LENS ,F1.6~3.8,f=4~88mm |
| A.E.S.: |
1/60~1/100,000 sec. |
1/50~1/100,000 sec. |
| Zoom: |
220X (22X Optical 10X Digital) |
| Focus: |
Auto / Manual |
| Position: |
64 Position (Zoom. Focus) |
| Video Output: |
1.0V p-p composite video at 75 ohm |
| Gamma Correction: |
0.45 |
| Gain Control |
AGC (18dB max) |
| White Balance: |
ATW / AWC / FIX |
| White Balance Range: |
ATW ( 3200---10000 ºK ) / AWB (Auto White Balance) / FIX( 3200 ºK ) |
| B.L.C. Function: |
Super BLC,48 zone BLC |
| Image Negative: |
Select by OSD Menu |
| Cross Line: |
On/Off Select by OSD Menu |
| Freeze Function: |
Alarm In Trigger Or Select By OSD |
| Control Function: |
Dry Switch, RS-232C(Drive Option), OSD Control |
| Operation Temperature: |
-10¡æ TO 50¡æ |
| Operation Humidity: |
within 85©‡RH |
| Power Source: |
DC 12V¡À1V / 3.6W (Max) |
|
