Key Feature:
* ABS material for outer cover and imported Acrylic out-cover and delicate design, black inner shell can monitor much sharper.
* Be compatible with common cassette mechanism of camera, like SONY, HITACHI ,LG and other famous brands with high resolution.
* Running smoothly with low speed, subwoofer noise and no image dithering
* 64 preset positions.
* 1 Patrol tracking routs and 1 auto level scan routs.
* Variable rotation£¨pan 0 ¡« 15º/s ;tilt 0 ¡« 15º/s£©; Auto level scan
* Continuous 360 º rotations in Omni-directions no fade zone; Rotation speed can be adjusted by tilting angle of the joystick
* RS485 integrated various protocols, PELCO-D, PELCO-P etc
* 3 class lightning defend, built in 3000V lightning proof, surge resistant
|
Electrical specifications |
| Power Input |
AC24V/2A (no identity "+" or "-") |
| Power Consumption |
20W |
|
Settings£º |
| Decoder |
Built-in |
| Preset Position |
64 presets |
| Left&Right Rotation Range |
360¡ãContinuous Rotation |
| Left&Right Speed |
0.1¡ã£15¡ã/S |
| Up&Down Rotation Range |
90¡ãVertical, 180¡ãAuto flip |
| Up&Down Speed |
0.1¡ã£15¡ã/S |
| Control Method |
RS485 |
| Protocol |
Pelco-P/D etc |
| Baud rate |
2400bps/4800bps/9600bps/19200bps |
|
Working environment£º |
| Working Temperature |
Indoor£º0ºC ~ 50ºC |
|
Physical£º |
| Packing Dimension(mm) |
L260mm*W230mm*H260mm |
| Weight (kg) |
Surface Mount: 2.6 Kg In-ceiling Mount: 3.44 Kg | |
