Computar H0514-MP2 Industrial lens Million Pixel HD 5MM 1.4 Manual Aperture C-Mount
Condition:New
Model:H0514-MP2
Warranty 1 year !
|
|
Computar H0514-MP2 Industrial lens Million Pixel HD 5MM 1.4 Manual Aperture C-Mount
| Focal Length |
16mm |
| Max. Aperture Ratio |
1:2.0 |
| Max. Image Format |
8.8mm x 6.6mm(¦µ11mm) |
| Operation Range |
Iris |
F2.0-F16.0 |
| Focus |
0.2m-Inf. |
| Control |
Iris |
Manual |
| Focus |
Manual |
| Object Dimension at M.O.D. |
8.8mm x 11.74cm 2/3" |
| Angle of View |
D |
2/3" |
37.7¡ã |
1/1.8" |
30.1¡ã |
1/2" |
28.0¡ã |
| H |
30.7¡ã |
24.3¡ã |
22.6¡ã |
| V |
23.3¡ã |
18.5¡ã |
17.1¡ã |
| Operating Temperature |
|
|
|
-10¡ãC~+50¡ãC |
|
|
|
| Distortion |
2/3" |
0.09%(y=5.5) |
1/1.8" |
0.06%(y=4.32) |
1/2" |
0.07%(y=4.0) |
| Back Focal Length |
14.7mm |
| Flang Back Length |
17.526mm |
| Mount |
C-Mount |
| Filter Size |
M27.0 P=0.5mm |
| Dimensions |
¦µ29mm x 33.53mm |
| Weight |
53G |
| Working Distance (mm) |
Optical Magnification (mm) |
Extension Ring (mm) |
Field of View(mm) |
| 2/3" |
1/1.8" |
1/2" |
| H |
V |
H |
V |
H |
V |
| 900 |
-0.018 |
- |
501.2 |
376.4 |
393.5 |
296.7 |
365.0 |
273.9 |
| 850 |
-0.019 |
- |
473.8 |
355.8 |
372.0 |
280.5 |
345.1 |
258.9 |
| 800 |
-0.020 |
- |
446.4 |
335.2 |
350.4 |
264.2 |
325.1 |
243.9 |
| 750 |
-0.021 |
- |
418.9 |
314.6 |
328.9 |
248.0 |
305.1 |
228.9 |
| 700 |
-0.022 |
- |
391.5 |
294.0 |
307.4 |
231.7 |
285.1 |
213.9 |
| 650 |
-0.024 |
- |
364.1 |
273.4 |
285.8 |
215.5 |
265.2 |
198.9 |
| 600 |
-0.026 |
- |
336.7 |
252.8 |
264.3 |
199.3 |
245.2 |
183.9 |
| 550 |
-0.028 |
- |
309.3 |
232.2 |
242.8 |
183.0 |
225.2 |
168.9 |
| 500 |
-0.031 |
- |
281.9 |
211.6 |
221.2 |
166.8 |
205.2 |
153.9 |
| 450 |
-0.035 |
- |
254.5 |
191.0 |
199.7 |
150.5 |
185.2 |
138.9 |
| 400 |
-0.039 |
- |
227.1 |
170.4 |
178.2 |
134.3 |
165.3 |
124.0 |
| 350 |
-0.044 |
- |
199.7 |
149.8 |
156.6 |
118.0 |
145.3 |
109.0 |
| 300 |
-0.0511 |
- |
172.2 |
129.2 |
135.1 |
101.8 |
125.3 |
94.0 |
| 250 |
-0.061 |
- |
144.8 |
108.6 |
113.6 |
85.6 |
105.1 |
79.2 |
| 200 |
-0.075 |
- |
117.4 |
88.0 |
92.0 |
69.3 |
85.3 |
64.0 |
| 150 |
-0.098 |
0.5 |
90.0 |
67.4 |
70.5 |
53.1 |
65.3 |
49.0 |
| 100 |
-0.142 |
0.5 |
62.5 |
46.8 |
48.9 |
36.8 |
45.4 |
34.0 |
|
|
|
|
